d07068.fm
SI-912 i-029 / SI-915 i-012
SI-916 i-007
SERVICE INSTRUCTION
08 February 2024 74-20-00
Initial Issue Page 3 of 15
Copyright - BRP-Rotax GmbH & Co KG. All rights reserved.
2) Material Information
2.1) Material
Price and availability will be provided on request by ROTAX
®
Authorized Distributors or their inde-
pendent Service Centers.
2.2) Company support information
- Any possible support by BRP-Rotax will be provided on request by ROTAX
®
Authorized Distribu-
tors or their independent Service Centers
- Shipping costs, downtime costs, loss of income, telephone costs etc. or costs of conversion to
other engine versions or additional work, as for instance simultaneous engine overhauls are not
covered in this scope and will not be borne or reimbursed by ROTAX
®
2.3) Material requirement per engine
Parts requirement:
Fig.no. Part no. Qty/engine Description Application
1-1 864660 (1) DOUBLE IGNITION
COIL 1 ASSY.
Spark plugs 1B, 2B
1-2 864661 (1) DOUBLE IGNITION
COIL 2 ASSY.
Spark plugs 1T, 2T
1-3 864662 (1) DOUBLE IGNITION
COIL 3 ASSY.
Spark plugs 3B, 4B
1-4 864663 (1) DOUBLE IGNITION
COIL 4 ASSY.
Spark plugs 3T, 4T
1-5 665621 (1) WIRING HARNESS
STANDARD
912 i Series
1-5 665623 (1) WIRING HARNESS
SHORT
912 i Series
1-5 665622 (1) WIRING HARNESS
SPECIAL
912 i Series
1-5 665681 (1) WIRING HARNESS
STANDARD
915 i A Series
1-5 665688 (1) WIRING HARNESS
STANDARD
915 i C24 Series
1-5 665683 (1) WIRING HARNESS
SHORT
915 i C24 Series
1-5 665681 (1) WIRING HARNESS
STANDARD
916 i A Series
1-5 665685 (1) WIRING HARNESS
STANDARD
916 iSc B
To Next Page
