Rotax 912 i series Service Instructions

d06703.fm
SI-912 i-024
SI-915 i-006
SERVICE INSTRUCTION
03 July 2019 76-10-00
Initial Issue Page 3 of 18
Copyright - BRP-Rotax GmbH & Co KG. All rights reserved.
2) Material Information
2.1) Material
Price and availability will be provided on request by ROTAX
®
Authorized Distributors or their inde-
pendent Service Centers.
2.2) Company support information
None.
2.3) Material requirement and credit per engine
Parts requirement for connector gasket replacement:
* Please contact your aircraft manufacturer for further support on material and instructions for pos-
sible further aircraft related modifications.
2.4) Material requirement and credit per spare part
None.
2.5) Rework of parts
None.
Fig.no. New p/n
Qty/
engine
Description Application
951981 1 Connector bracket*
481510 1 Connector set stator Lane B
consist of:
864590 1 Connector housing Amphenol
®
864595 1 Connector housing Amphenol
®
864600 4 Faston connector housing Amphenol
®
864605 4 Contact pin male Amphenol
®
864610 2 Sealing plug

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
