1
3
4
2
Effectivity: 914 Series BRP-Powertrain page 7-3
OM Edition 2 / Rev. 0 April 01/2009
d04479.fm
Cooling system
Fig. 1 09152
Part Function
1 expansion tank
2radiator
3 pressure cap
4 overflow bottle
