Rotax 914 series - Page 71

AUX MAIN
1
3
4
5
3
3
6
6
7
1
2
5
8
Effectivity: 914 Series BRP-Powertrain page 7-5
OM Edition 2 / Rev. 0 April 01/2009
d04479.fm
Fuel system
Fig. 2 00103
Part Function
1 fuel tank
2 filter/water trap
3 electric fuel pumps
4 fuel pressure control
5 carburetor
6 check valve
7 return line
8 airbox
