23
Table 4-2
PERFORMANCE CHECK LIST
Date: ____________
Model: ____________
S/N: ____________
Temperature: ____________
Humidity: ____________
Voltage Accuracy:
See paragraph 4.2.1
Volts
(V)
Watts
(W) PF 50Hz
Limit
(%) 60Hz
Limit
(%) 400Hz
Limit
(%)
80 80 1.0 ±0.022
±0.022
120 120 1.0 ±0.021 ±0.024 ±0.021
240 240 1.0 ±0.024 ±0.024 ±0.024
555 555 1.0 ±0.021 ±0.021
749 749 1.0 ±0.021 ±0.021
Current Accuracy: See paragraph 4.2.2
Freq.
(Hz)
Volts
(V) VA PF
Amps
(A)
MSB
Range
Max.
Limit (V)
Min.
Limit (V) Reading
Spec.
(%)
50 120 1200 1.0 10.000 10 10.0026 9.9974 ±0.026
50 101 561 1.0 5.5545 5 9.3526 9.3476 ±0.027
50 101 113 1.0 1.1188 1 9.4199 9.4133 ±0.035
50 120 120 1.0 1.0000 1 10.0035 9.9965 ±0.035
50 120 12 1.0 .10000 1 1.0012 0.9987 ±0.125
50 120 6000 1.0 50.000 50 10.0036 9.9964 ±0.036
400 120 1200 1.0 10.000 10 10.0026 9.9974 ±0.026
400 120 120 1.0 1.0000 1 10.0035 9.9965 ±0.035
400 120 12 1.0 .10000 1 1.0012 0.9987 ±0.125
400 120 6000 1.0 50.000 50 10.010 9.990 ±0.100
Voltage Distortion:
See Paragraph 4.2.3
Volts
(V)
Watts
(W) PF
Load
(Ohms) 50Hz
Limit
(%) 400Hz
Limit
(%)
120 120 1.0 900 ±0.05 ±0.05
240 240 1.0 3.6 ±0.05 ±0.05
Current Distortion:
See paragraph 4.2.4
Volts
(V)
Watts
(W) PF
Amps
(A) 50Hz
Limit
(%) 60Hz
Limit
(%)
Comp.
Voltage
120 1200 1.0 10.000 ±0.05 ±0.05 1V(.1)
