Table 4-2
PERFORMANCE CHECK LIST
Date: ____________
(CONTINUED) Model: ____________
S/N: ____________
Power Accuracy:
4.2.5
Freq. Volts I 800A/811A 800AE/811AE
(Hz) (V) V-A (A) PF Lag Lead Max. Min. Max. Min.
50 120 600 5 1.0 10.005
0
9.9950 10.001
0
9.9990
50 120 600 5 0.7 7.0120 6.9880 7.0010 6.9990
50 120 600 5 0.5 5.0120 4.9880 5.0010 4.9990
50 120 600 5 0.0 0.0120 -0.0120 0.0010 -0.0010
400 120 600 5 0.0 0.0220 -0.0220 0.0110 -0.0220
50 120 6000 50 0.0 0.0135 -0.0135 0.0135 -0.0135
50 120 6000 50 1.0 10.006
5
9.9935 10.006
5
9.9935
400 120 6000 50 0.0 0.0220 -0.0220 0.0220 -0.0220
400 120 6000 50 1.0 10.012
0
9.9880 10.012
0
9.9880
50 240 1200 5 1.0 10.005
0
9.9950 10.001
0
9.9880
50 240 1200 5 0.0 0.0120 -0.0120 0.0010 -0.0010
Deviation Accuracy: Paragraph 4.2.6
PF Lead/Lag
Deviation
Range
Deviation
Setting
DVM
Reading
Limit
Maximum
Limit
Minimum
1.0 Lag 1% -1.00 1.020 0.980
0.8 Lag 1% -1.00 1.270 1.230
0.8 Lead 1% -1.00 1.270 1.230
0.7 Lag 1% -1.00 1.449 1.409
0.8 Lead 1% 1.00 -1.230 -1.270
0.8 Lead 0.1% 0.10 -0.123 -0.127
Fractional Divider:
See Paragraph 4.2.7
Fractional
Divider Setting Amps Maximum Minimum Reading
Limit
(%)
4/5 4 8.0100 7.9900 ±0.125
3/5 3 6.0075 5.9925 ±0.125
2/5 2 4.0050 3.9950 ±0.125
1/5 1 2.0025 1.9975 ±0.125
3/4 3.75 7.5094 7.4906 ±0.125
1/2 2.5 5.0063 4.9938 ±0.125
1/4 1.25 2.5031 2.4969 ±0.125
