3 INTRODUCTION TO THE RLD-7.2 AND RLD-14
The RLD-7.2 and RLD-14 units enable controlling the light and brightness in the poultry pen. The Rotem
Platinum, AC-2000 and SuperGuard Controllers support the RLD. This manual is meant to be used by
either a poultry farmer or authorized personnel who own a poultry pen.
• Device Description
• Software Type
• Abbreviations and Terms
• User Interface
3.1 Device Description
The RLD-7.2 and RLD-14 are two independent channel devices controlling all light functions inside the
poultry house. These dimmers have unique features such as stable operation in low brightness levels and
high flexibility.
Main features:
• Two independent channels
• Manual brightness control
• Programmable brightness control by analog signal 0 - 10 VDC and communication line from the
controller
• *Automatic settings recovery after power failure
• Automatic settings save for each mode.
• Minimum and maximum light intensity settings
• Automatic shut down timer.
• Maximal output power for one channel
o 230 VAC, 7200 VA (RLD-14)
o 110 VAC, 3600 VA (RLD-7.2)
NOTE: *The settings are immediately saved after being defined
3.2 Software Type
Rotem currently supports two software versions:
• Version 3.0 supports:
o CPU card version 1.3.1 (refer to Figure 6)
• Version 4.01 supports:
o CPU card version 2.0 (refer to Figure 5)
