10 x Technical data
113
FA ROTEX HeatPumpSolarUnit - Part 2 - 05/2009
Refrigerant (factory set)
Type R410A R410A
Filling quantity kg 1.7 3.7 2.95 3.7 2.95 3.7 2.95
Additional refrigerant filling quantity
From pipeline length m 10 30 10 30 10 30 10
Filling quantity kg/m 0.02 see Tab. 4-8, Page 60
Refrigerant oil
Type FVC50K FVC68D
Filling quantity litres 0.75 1
Defrost process
Procedure Reverse cycle Pressure compensation
Control Sensor for temperature of the outside heat exchang-
er
Sensor for temperature of the outside heat exchanger
Connections stop valve liq- uid line
Type Flanged connection Flanged connection
External diameter inches 1/4" ET 3/8" ET
Connections stop valve gas line
Type Flanged connection Flanged connection
External diameter inches 5/8" ET 5/8" ET
Connections discharge valve
Number 1 3
Type Hole Hole
External diameter mm 18 26
Pipe length between Indoor and Outdoor Module (min./max.)
m 3 to 30 5 to 75
Max. height difference between Indoor and Outdoor Module
m20 30
Operating range
Room heating
(min./max.)
°C (WB) -20 to 25 -20 to 35
Room cooling
(min./max.)
°C (DB) 10 to 43 10 to 46
Water heating
(min./max.)
°C (DB) -20 to 43 -20 to 43
Output control Inverter controlled Inverter controlled
6 to 8 kW 11 to 16 kW
Unit RRHQ006...V RRHQ007...V RRHQ008...V RRHQ011...V RRHQ011...W RRHQ014...V RRHQ014...W RRHQ016...V RRHQ016...W

Rotex HPSU 6-8X Specifications

General

Brand	Rotex
Model	HPSU 6-8X
Category	Inverter
Language	English
