10 x Technical data
112
FA ROTEX HeatPumpSolarUnit - Part 2 - 05/2009
10 Technical data
10.1 Basic data
10.1.1 Outdoor Module (RRHQ)
6 to 8 kW 11 to 16 kW
Unit RRHQ006...V RRHQ007...V RRHQ008...V RRHQ011...V RRHQ011...W RRHQ014...V RRHQ014...W RRHQ016...V RRHQ016...W
Dimensions and weights
Dimensions (H x W x D) cm 73.5 x 82.5 x 30 117 x 90 x 32 134.5 x 90 x 32 117 x 90 x 32 134.5 x 90 x 32 117 x 90 x 32 134.5 x 90 x 32
Total weight (filled with refrigerant) kg 56 103 110 103 110 103 110
Heat exchanger
Length cm 84.5 85.7
Number of lines 2 2
Type of fin WF fin WF fin
Fin spacing mm 1.8 1.4
Surface treatment Treated with anticorrosion protection (PE) Treated with anticorrosion protection (PE)
Number of levels 32 526052605260
Pipe type Hi-Xa(8) Hi-XSS(8)
Electric fan
Type Axial fan Axial fan
Number per Outdoor Module 1 2
Nominal output kW 0.053 0.07
Refrigerant compressor
Number per Outdoor Module 1 1
Type Fully hermetic reciprocating compressor Fully hermetic scroll compressor
Model JT100G-VD 2YC63BXD#C JT1G-VDYR@S 2YC63BXD#C JT1G-VDYR@S 2YC63BXD#C JT1G-VDYR@S
Start-up method Inverter controlled Inverter controlled
Nominal output kW 1.92 2.2
Output crankcase heating kW — 0.033
Refrigerant circuit
Number of circuits 1 1
Control type Electronic expansion valve Electronic expansion valve
