10 x Technical data
136
FA ROTEX HeatPumpSolarUnit - Part 2 - 05/2009
Fig.10-27 Electric circuit diagram Indoor Module (RKHB) 11-16 kW with Backup Heater (BH) 6WN / 9WN
