Rotex Posidapt Series - Table of Contents

RTX-IOM-PRODUCT-YY
Page 2 of 131
www.rotexautomation.com
Contents
1. Posidapt Product Summery.................................................................................... 6
1.1. Key Features .......................................................................................................... 6
1.2. Posidapt Series ....................................................................................................... 7
2. Technical Specification .......................................................................................... 8
3. Posidapt Overview ............................................................................................... 14
4. Bock Diagram: ...................................................................................................... 17
5. Dimensional Drawing: .......................................................................................... 18
6. Installation / Mounting: ......................................................................................... 19
6.1. Safety Instructions: ............................................................................................... 19
6.2. Mounting Positioner on Control Valve: .................................................................. 22
6.3. Mounting Positioner on a Rotary Actuator: ........................................................... 26
6.4. Mounting Positioner with bearing assembly on a Rotary Actuator. ....................... 29
6.5. Mounting Positioner with the bearing assembly on a Control Valve: .................... 32
6.6. Remote Mounting. ................................................................................................ 36
6.7. Mounting remote unit on Rotary Actuator ............................................................. 36
6.8. Mounting remote unit on a Control Valve. ............................................................. 40
6.9. Unfavourable mounting conditions. ....................................................................... 43
7. Electrical Connection ........................................................................................... 44
8. User Interface ....................................................................................................... 45
8.1. Menu Structure ..................................................................................................... 45
8.2. Display Screen...................................................................................................... 47
8.3. Parameter Overview – DTM & Display ................................................................. 48
8.3.1. Basic Setup .................................................................................................... 48
8.3.2. Calibration ...................................................................................................... 54
8.3.3. Advanced Setup ............................................................................................. 58
