Rottler SGF8 - Page 23

Machine Parts 11-4 SG8 Manual
WORKHEAD ASSEMBLY
PLATE NO. - 2
S. NO. DESCRIPTION QTY/M/C
1 BASE 1
2 SET SCREW 5/16” NF X 3/8” 4
3 PLUG (BRASS) 16
4 BALL BEARING 6) 555-14-29
5 WASHER OD 0.350”, ID 0.203” X 0.05” THK 8) 555-14-30
6 ECCENTRIC PIN 2) 555-14-31
7 PLATE 2) 555-14-32
8 GRUB SCREW 10-32 X ¼” DOG PT. 2) 555-14-33
9 WASHER 3/8” 8) 555-14-34
10 HEX. HD. SCREW 3/8” BSW X 5” 4
11 PIN 2) 555-14-35
12 PIN 2) 555-14-36
13 GRUB SCREW 10-32 X ¼” FLAT PT. 2
14 WEIGHT 1
15 ALLEN HD. SCREW (1/2” UNC X 2.5”) 2
16 SWIVALING BLOCK 1
17 ALLEN HD. SCREW 2
18 SWIVALING PIN 1
19 PIN HOLDER 1
20 GRUB SCREW ¼” BSW 1
21 WASHER 1
22 NUT 3/8” BSW 1
23 BUSH 4
24 LEVER 4
25 HAMMER RIVIT 16
26 NYLOCK NUT 3/8” BSW 4
27 CYLINDER (LH) 1
28 GUIDE PIN 4
29 LEVER 2
30 PISTON 2
31 PIN 2
32 PISTON PIN 4
33 SPRING 4
34 ‘O’ RING 2
35 GRUB SCR. 8-32 X 20mm F. POINT 4
36 BRACKET 4
37 BUTTON HD SCR 10-32 X 1/4” 4
38 CYLINDER (RH) 1
39 NUT ( NEST) 1
40 STUD 1
41 SPACER 1
42 ADJUSTING NUT 1
43 RETAINING RING 1
44 INCLINATION ROD 1
45 RETAINING RING 2
46 SPRING PIN 1/8” X 3/4” 2
47 NEEDLE BEARING 1
48 THRUST BEARING 2
49 KNOB 1
