Machine Parts 11-5 SG8 Manual
51 SET SCREW 5/16” BSW X ¼” F.PT. 1
S. NO. DESCRIPTION QTY/M/C
52 HANDLE 1
53 ALLEN HD SCREW 5/16” BSW X 2.50’ 1
54 NYLOCK NUT 3/8” UNF 1
55 NUT 2
56 EYE BOLT 1
57 ECCENTRIC COLLAR 2
58 LEVER 1
59 KNOB 1
60 PIVOT PIN 1
61 ECCENTRIC COLLAR 2
62 TAPER PIN 2
63 RING 1
64 ALLEN HEAD SCR. ¼” BSW X ½” LONG 4
65 CLAMP 1
66 LEVER 1
67 KNOB 1
68 CLAMP PLATE (NOT SHOWN) 1
69 BASE COVER PLATE (NOT SHOWN) 1
