SPINDLE ASSEMBLY
PLATE NO. - 3
S. NO. DESCRIPTION QTY/M/C
1 DRIVE SHAFT 1
2 RUBBER SEAL 1
3 QUICK NUT 1
4 SPRING 2
5 PAD 1
6 TAPER ROLLER BEARING 1
7 COLUMN 1
8 BALL BEARING 1
9 PLATE 1
10 BRASS PAD 2
11 C.PT. GRUB SCR. 3/16” X 1/2” BSW 2
12 F.PT GRUB SCR. 3/16” X 1/2” BSW 1
13 STOP PLATE LOCK NUT 1
14 LOCK WASHER 1
15 LOCK NUT 2
16 END STOPPER 1
17 TENSION GAS SPRING (150N) 1
18 SUPPORT TUBE WELED 1
19 HINGE 1
20 ALLEN SCREW 3/16” BSW X ½” LONG 1
21 EXTENSION BLOCK LEFT 1
22 EXTENSION BLOCK RIGHT 1
23 SPINDLE HOUSING 1
24 GRUB SCR. D.PT. 5/16” NF X 1.25” LONG 4
25 ALLEN SCREW 5/16’ NF X 1.5” LONG 5
26 GRUB. SCR. D. PT. 5/16” NF X 1/2" LONG 1
27 GRUB SCR. F. PT. 5/16” NF X 0.200” LONG 1
28 GRUB SCREW 3/8” BSW X ½” LONG 1
29 BRASS PLUG 1
30 CONTROL STOP SCREW 1
31 C’SINK SCR. ¼” X ½” BSW 2
32 CONTROL STOP LATCH 1
33 CLAMP 1
34 PIN 1
35 SPRING 1
36 KNOB 1
37 SET SCR. F. PT. 5/16” NF X 3/8” LONG 1
38 C’ SINK SCR. 10-32 X ¼” LONG 1
39 END COVER 1
40 WASHER 1
41 WORM SHAFT 1
42 BUSH 1
43 PINION 1
44 WOODRUF KEY 1
45 WORM WHEEL 1
46 PIN 2
47 SPACER 1
48 HAND WHEEL 1
49 KNOB
50 COVER PLATE 1
51 C’ SINK SCREW 4
