Machine Parts 11-3 SG8 Manual
SPINDLE ASSEMBLY
PLATE NO. - 3
S. NO. DESCRIPTION QTY/M/C
52 WASHER 1
53 C’SINK SCR.1/4” X 1/2” BSW 1
54 M4-BALL PLUNGER SCREW 1
55 INDICATOR MTG. FLAT 1
56 INDICATOR MTG. ROD 1
57 DIAL CLAMP 1
58 INDICATOR 1
59 KNOB 1
60 LEVELING PIN 1
61 PLATE (LEVELING PIN) 1
62 CONTROL PANEL MOUNTING 1
63 RIGHT SIDE COVER 1
64 LEFT SIDE COVER 1
65 TOP COVER 1
66 BACK COVER FRAME 1
67 BACK DOOR 1
68 FIX BLOCK 2
69 SWING BLOCK 2
70 PIN 2
71 SCREW 3/8” BSW X 1.00” 1
72 BALL BEARING 1
73 CUNTER WEIGHT PULLEY 1
74 WASHER ¼” 1
75 ALLEN SCREW ¼” X ½” 2
76 COUNTER WEIGHT PLATE 1
77 C’SINK SCR. 10-32 X ½” LONG 3
78 COUNTER WEIGHT BKT . 1
79 PULLEY COVER (COUNTER WEIGHT) 1
80 HOLDER 1
81 GAS SPRING (150N)
1) Shock-SG8
82 GAS SPRING MTG.
1) 555-14-37
