Bonnet Opening
Bonnet Opening
BONNET OPENING
DO NOT drive with the bonnet retained by the safety catch
alone.
1. From inside the car, pull the bonnet release handle.
2. Release the bonnet safety catch. Dependent on the model,
one of two different release mechanisms will be fitted:
A. Push the lever mounted on the bonnet locking platform
towards the rear of the car.
B. Lift the lever, which protrudes through the front grille.
3. Raise the bonnet.
Closing the bonnet
Lower the bonnet. When the bonnet is approximately 150 mm
from its closed position, push down evenly using the palms of both
hands on the leading edge of the bonnet on either side of the
radiator grille.
After closing the bonnet, check that the lock is fully engaged by
attempting to lift the front edge of the bonnet. This should be free
from all movement.
1
A B
HB0232a
