223
Puncture Repair & Wheel Changing
5
SPARE WHEEL & TOOLS (Saloon)*
HB0643
1
2
7
6
5
4
3
1. Spare wheel.
2. Spare wheel clamp.
3. Wheel bolt spanner.
4. Jack.
5. Jack handle.
6. Wheel bolt cover removal tool
*.
7. Locking wheel bolt removal tool
*.
NOTE: The fitment of a space saver or full size
spare wheel and associated tools is available as an
option at the time of manufacture and replaces the
Instant Tyre Repair (ITR) system.
If a spare wheel is supplied, the specification will
vary according to model type. If a space saver
spare wheel is supplied, remove the spacer (fitted
beneath the spare wheel clamp) before stowing a
full size road wheel.
For information on how to change the wheel,
please refer to ‘CHANGING A WHEEL’,
page 227.
