Bulb Replacement
239
5
HEADLIGHT AND SIDELIGHT - Cars with Halogen
Projector (blue vision) lights
Inboard headlights (main beam)
Replacement bulb: H9 65 watt.
1. Remove the rubber cover from the rear of the headlight.
2. Twist the bulb holder one eighth of a turn anti-clockwise to
release from the light unit.
3. Release the clips on either side of the electrical connector (see
inset) and detach from the bulb. When refitting, note that the
connector fits one way round only.
Replacement of the bulb is a reversal of the above process.
Sidelight
Replacement bulb: 5 watt (blue vision).
The sidelight bulb holder is immediately below the inboard
headlight bulb (see small inset on previous illustration). With the
circular rubber cover removed, pull the bulb holder from the light
unit and pull the bulb to remove it from the holder.
HB0048a
2
1
3
