Bulb Replacement
249
5
NUMBER PLATE LIGHTS (Saloon)
Replacement bulb: 5 watt.
There are two number plate lights. On saloon models, remove the
two securing screws and the lens to access each bulb.
Pull the bulb to remove.
NOTE: When replacing, ensure the lens is fitted the correct way round;
the curved face should point towards the rear.
NUMBER PLATE LIGHTS (Tourer)
Replacement bulb: 5 watt.
To access a bulb, use a small flat-bladed screwdriver to ease the lens
from the underside of the applique (see upper inset - the lever
action of the screwdriver will compress the spring retaining clip
and enable the lens to be pulled free). Prise the connectors apart to
remove the bulb.
When replacing the lens, fully insert the end opposite to the spring
clip, then push the side with the spring clip into place.
H2705
HB0039a
