264
Technical Data
DIMENSIONS (Tourer)
AB
D
E
G
F
HB0043b
C
Overall length - A 4792 mm
Overall width (inc. mirrors) - B 1970 mm
Overall height (with roof bars) - C
- 75 models 1477 mm
- ZT-T models 1470 mm
Wheelbase - D 2746 mm
Front overhang - E 914 mm
Rear overhang - F 1131 mm
Ground clearance (between axles) - G 155 mm
Maximum overhang of coupling point 1208 mm
Turning circle (kerb to kerb) 11.36 m
Approach angle 18.6°
Departure angle 19.5°
