Royal Enfield Bullet EFI User Manual

ROYAL ENFIELD VEHICLE SERVICE MANUAL - EURO IV
3
TABLE OF CONTENTS
SL.NO. DESCRIPTION PG.NO.
SL.NO. DESCRIPTION PG.NO.
ROYAL ENFIELD VEHICLE SERVICE MANUAL - EURO IV
03
1. Technical Specifications ............................................ 4
2. Periodical Maintenance ............................................. 6
3. Special Tools Usage List ............................................. 8
4. Engine Removal from Frame..................................... 9
5. Vehicle Aggregagetes
5.1 Cables ............................................................... 11
5.2 Airfilter Paper Element .................................. 16
5.3 Fuel Tank .......................................................... 23
5.4 Seat Assembly ................................................. 30
5.5 Exahust Pipe & Silencer ................................. 39
6. Front Suspension
6.1 Front Wheel ..................................................... 46
6.2 Front Mudguard .............................................. 54
6.3 Handle Bar ....................................................... 60
6.3 Front Fork ........................................................ 70
6.4 Steering Stem .................................................. 87
7. Rear Suspension
7.1 Rear Wheel....................................................... 103
7.2 Rer Sprocket / Drive Chain Adjustment ....... 111
7.3 Rear Shockers .................................................. 113
7.4 Rear Mudguard / Rear Number Plate ........... 119
7.5 Swing Arm ........................................................ 126
8. ABS ........................................................................... 133
9. EVAP ........................................................................... 167
10. EMS ........................................................................... 174
11. NACS II DIAGNOSIS ..................................................... 213
12. Electricals
12.1 Battery .............................................................. 233
12.2 Bulbs ................................................................. 239
12.3 Electrical Components ................................... 261
12.4 Wiring Diagram ............................................... 277
13. Trouble Shooting ........................................................286
KS MOTORCYCLES - http://ksmotorcycles.com

Royal Enfield Bullet EFI Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Displacement	346 cc
Maximum Power	19.8 bhp @ 5250 rpm
Maximum Torque	28 Nm @ 4000 rpm
Fuel System	Electronic Fuel Injection (EFI)
Ignition	Digital Electronic Ignition
Gearbox	5 Speed Constant Mesh
Clutch	Wet, Multi-plate
Frame Type	Single Downtube, Using Engine As Stressed Member
Front Suspension	Telescopic, 35mm Forks, 130mm Travel
Rear Suspension	Twin shock absorbers with 5-step adjustable preload
Front Brake	280mm Disc, 2-Piston Caliper
Rear Brake	153mm Drum, Single Lead Internal Expanding
Front Tyre	3.25 x 19
Rear Tyre	3.25 x 19
Fuel Tank Capacity	13.5 Litres
Seat Height	800 mm
Ground Clearance	135 mm
Wheelbase	1370 mm
