SECTION 01 - TECHNICAL SPECIFICATION
TECH SPEC POINT
BULLET
CLASSIC EFI
CONTINENTAL GT
BULLET EFI
ROYAL ENFIELD VEHICLE SERVICE MANUAL - EURO IV
04
ENGINE
Engine 4 Stroke, air cooled, single cylinder 4 Stroke, air cooled, single cyl., OHV, SI
Capacity 499 cc (Displacement) 535 cc
Bore 84 mm 87 mm
Stroke 90 mm 90 mm
Compression ratio 8.5 : 1 8.5 : 1
Max. Power @ RPM 20.3 Kw @ 5250 RPM 21.4 kw @ 5100 RPM
Max. Torque @ RPM 41.3 Nm @ 4000 RPM 44 Nm @ 4000 RPM
Air filter Element Paper Element Paper Element
Lubrication Forced Lubrication, Wet Sump Forced Lubrication, Wet Sump
Fuel Supply Electronic Fuel Injection Electronic Fuel Injection
IGNITION SYSTEM
Ignition system Digital Electronic Ignition Electronic Ignition
Spark plug gap 0.8 mm 0.8 - 0.9 mm
Spark plug WQR8DC (Bosch) WQR8DC (Bosch)
TRANSMISSION
Clutch Wet Multiplate Wet Multiplate (7 Plates)
Drive Chain links 102 pitch 101 pitch 101 Pitch
Primary drive Duplex Chain drive 3/8” pitch Duplex Chain
Gear box 5 Speed Constant Mesh Constant Mesh 5 Speed
Gear Ratios
I - 3.063 : 1 I - 3.063 : 1
II - 2.013 : 1 II - 2.013 : 1
III - 1.522 : 1 III - 1.522 : 1
IV - 1.212 : 1 IV - 1.212 : 1
V - 1.000 : 1 V - 1.000 : 1
Primary Drive Ratio 2.15 : 1 2.15 : 1
Secondary Drive Chain Drive 18 Teeth (F.D. Sprocket)
Secondary ratio 2.235:1 2.12:1
ELECTRICALS
Generation Alternator Alternator
System 12V DC 12V DC
Battery 12V - 14 AH 12V - 14 AH
Head lamp 12V, 60/55 W 12V, 60/55 W, Halogen Bulb
Tail / Brake lamp 12V, 5/21 W 5/21 W
Turn signal 12V, 10W X 2 Nos. 12V, 10W X 4 Nos.
Pilot lamp 12V, 2 W X 2 Nos. / 12V, 4 W X 1 No. NA
Instrument Cluster NA Digital instrument Cluster with LCD
High beam indicator NA 12V, 0.2W (LED)
Neutral Indicator NA 12V, 1.12W
Horn 12V, 2.5 Amp (Max.) 12V, 2.5A (Dual tone-LT, HT)
Starter Motor NA 12V, 0.9 KW
