68
5.11 - Removing / Adding the Keel
a)
b)
c)
d)
To remove the keel with the boat on a crane, rst drop the boat down so that
the chocks at the top of the keel are accessible.
Remove the two chocks from the keel
using a 2 x 13mm spanners.
If the weed cutter is tted, remove the
rope bobble.
Lift the boat off the keel.
It is very important that you lift the boat evenly.
To add the keel, reverse this process.
