RS SAILING 21 - 4.1 - Stanchions and Guard Rails Installation

6
4.1 - Stanchions and Guard Rails
a)
b)
d)
c)
Add the 4 stanchions and
replace the screws.
4 x Stanchions 2 x Guard rails 4 x Guard rail ties
Locate the following items:
Remove the retaining screws from
each of the four stanchion bases.
Note: The guard rail ties differ for the regular and race versions.
Race spec has spliced loop.
Not the adjustable end.
Standard spec has no splice.
