2.2.12 0x200C Motor parameters
Object
Dictionary
Name
Property
Type
Scope
Default
Remarks
0x200C:01
Motor type
R/W/S
UINT
0~1
0
0—— Two-phase
stepper motor
1—— Three-phase
stepper motor
0x200C:02
Resistance Auto
R
UINT
100~
65535
1000
When automatic PI is
turned on, the motor
winding resistance value
is recognized.
Unit: mOhm
0x200C:03
Inductance Auto
R
UINT
0~
10
1
When automatic PI is
turned on, the motor
winding inductance
value is recognized.
Unit: mH
0x200C:04
Resistance Set
R/W/S
UINT
0~
10000
1000
Motor winding
resistance value
Unit: mOhm
0x200C:05
Inductance Set
R/W/S
UINT
1~10
1
Motor winding
inductance value
Unit: mH
0x200C:06
BEMF coefficient
R/W/S
UINT
0~1000
256
ECT60
Servo Mode 1:
When ECT60 works in servo mode 1, the motor parameters themselves do not participate in
motor control, and the user does not need to make special settings. The user can judge
whether the motor connection is normal by checking the self-identifying resistance and
inductance of the object.
Servo Mode 2:
When ECT60 driver works in servo mode 2, the closed-loop stepper motor is in FOC control
mode. Due to the special structure of the stepper motor, a weak magnetic control is required for
