ECT Series User Manual
21
ECT60 returns the actual speed, and the value returned by ECR60 = given speed.
2.2.27 0x2048 Voltage
Object
Dictionary
Name
Property
Type
Scope
Default
Unit
0x2048
Bus Voltage
R
UINT
---
0
10 mV
bus voltage value (V)= object value/100;
2.2.28 0x2049 Input level
Object
Dictionary
Name
Propert
y
Type
Scope
Default
Unit
0x2049
Input Level
R
UINT
---
0
---
Displays the physical level of the current IO input.
Bit15~bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
---
IN 6
IN 5
IN 4
IN 3
IN 2
IN1
0—— No input signal
1—— Input signal
2.2.29 0x204A Output level
Object
Dictionary
Name
Propert
y
Type
Scope
Default
Unit
0x204A
Output Level
R
UINT
---
0
---
Displays the physical level of the current output port.
Bit15~bit2
Bit1
Bit0
---
OUT2
OUT1
0—— Indicates that the current output port has an output
1—— Indicates that the current output port has no output
2.2.30 0x2060 Harmonic amplitude of the first resonance point
Object
Dictionary
Name
Property
Type
Scope
Default
Unit
0x2060
Amplitude of First Anti-Vibration
R /W /S
UINT
0-1000
0
---
Used to eliminate the vibration of the first resonance point of the two-phase stepper motor. This
