ECT Series User Manual
12
The port function is defined as follows:
Value
Function
0
Custom output
1
Alarm output
2
Brake output
3
In place output
When set as a custom output, the state of the port can be controlled by the polarity setting of
0x2006.
2.2.6 0x2006 Output port polarity
Object
Dictionary
Name
Property
Type
Scope
Default
Unit
0x2006
Outputs Polarity
R/W/S
UINT
0~3
3
---
Set the normally open and normally closed characteristics of the output port: Bit0 is the polarity
setting for output port 1, Bit1 is the polarity setting for output port 2.
0—— Normally closed
1—— Normally open
Bit15~bit2
Bit1
Bit0
---
OUT2
OUT1
2.2.7 0x2007 Input port function
Object
Dictionary
Name
Property
Type
Scope
Default
Unit
0x2007:03
Input 3Function
R/W/S
UINT
0~8
1
---
0x2007:04
Input 4Function
R/W/S
UINT
0~8
2
---
0x2007:05
Input 5Function
R/W/S
UINT
0~8
3
---
0x2007:06
Input 6Function
R/W/S
UINT
0~8
6
---
ECT60 contains 4 input ports, this object is used to set the function corresponding to the input
port.
