AUDIO DISTRIBUTION
Technical Support: support@rticontrol.com - Customer Service: custserv@rticontrol.com 32
Option Description
DSP Preset Editor
dialog box to select a DSP settings le that contains a single preset that will
overwrite the selected preset. Please note that this action cannot be undone.
The source le for this import process must be from the export (Single) le
from this or another similar RTI AD series audio product.
Export (Single): The export action will require choosing a preset to save prior
to using the export action. Select a preset to edit using the dropdown box
under the Edit DSP Preset header in the section below then use the Export
button under the Import/Export Single Presets header to open a dialog box to
save a DSP settings le that contains the selected preset. This le can be used
as a backup or saved for use with other RTI AD series products.
• Copy DSP Preset: Use this option to copy a selected DSP preset to another
slot/position. This is useful for replicating an existing DSP preset and using
it as a starting point for testing or adjusting settings without losing any
currently saved DSP preset.
To copy a DSP preset, rst select an existing one from the dropdown box
under the Copy From header. Next, select a DSP preset slot in the dropdown
box under the Copy To header. The selected preset can be empty or contain
an existing prole. Lastly, click on the COPY button to initiate the copy
function. Please note that this action cannot be undone, so please make
sure that all selectable options are correct before proceeding with the copy
procedure. It may be worthwhile to export all presets as a backup to revert to
previous settings if needed.
• Edit DSP Preset – These settings are used to dene a DSP preset by
generating an equalization curve based on the settings of up to 5 frequency
points along with their bandwidth and level (i.e. parametric equalization).
Additionally, low/high shelf lters and low/high pass lters can also be added
in conjunction with the parametric EQ to obtain a desired equalization
outcome.
Select DSP Preset to Edit: Select the DSP preset that is intended to be
modied by choosing a preset prole from the dropdown box provided. Up
to 9 proles can be edited and saved.
Edit DSP Name: It is recommended to give the DSP preset a name for easy
identication. The name entered here will be visible in various locations of
the GUI where DSP presets are referenced. Please note that the name is
To Next Page
