Panel Description
AD-1616 Front Panel
AD-1616 Rear Panel
No. Name Description
1 Power Button Powers on/o the matrix
2 Power LED
Indicator
3 Status LED
Indicator
❶ ❷ ❸
No. Name Description
4 Analog Audio
Inputs and
Outputs
Left and Right RCA mono channel pairs with loop-outs for external audio use /
extension of each source
5 Digital Audio
Inputs and
Outputs
Coaxial and Optical S/PDIF digital audio inputs that support a maximum of
2 channel LPCM audio. Digital inputs 9 and 10 also includes loop-outs for
external audio use/extension.
❹ ❺
❾ 󱢳 󱢴❻ ❽❼
