AUDIO DISTRIBUTION
Technical Support: support@rticontrol.com - Customer Service: custserv@rticontrol.com 6
No. Name Description
6 TCP/IP and
RS-232 Control
Interfaces
Ethernet connects to a TCP/IP local area network for WEB GUI access and 3rd
party control. For serial control, connect this port directly to an RTI processor
via a standard CAT-5e or better patch cable.
7 5-12V Output
Triggers
This matrix can control up to 4 additional devices using these output triggers.
This connection accepts a 3.5mm mono (TR) plug that is then connected to
downstream devices to manage their power states.
8 IR In and Out Control this matrix using IR commands using either a direct connection to a 3rd
party control system or an external IR receiver (sold separately) connected to
the IR In port. Received IR input signals are concurrently relayed out of the IR
Out port to allow daisy-chaining multiple matrix.
Please note that the IR command set is a subset of all available commands.
9 Stereo Zone
Pre-Outputs
16 Left and Right RCA mono channel pairs with variable level outputs to be
connected to an external matrix or processor.
10 IEC Power
Connector and
Fuse
Connect to an appropriately rated power source using the included IEC power
cable.
11 Product
Information QR
Code
Scan this QR code with a mobile device for quick and easy access to installation
and other product resources (internet required).
