AUDIO DISTRIBUTION
Technical Support: support@rticontrol.com - Customer Service: custserv@rticontrol.com 34
Option Description
DSP Preset Editor
Crossover: Crossover control is implemented as low/high pass lters that will
split the frequency bands, cutting o frequencies above or below their set
points. Options are:
- Low Pass: Setting the low pass lter will decrease all frequencies above
a set point and includes a per-octave roll-o lter. The lter type can be
set to dictate how aggressive the slope decreases the amplitude of the
frequencies above the set point.
Frequency: Set between 20Hz to 20kHz.
Filter Type: Set to 6dB, 12dB, 18dB, or 24dB
- High Pass: Setting the high pass lter will decrease all frequencies below
a set point and includes a per-octave roll-o lter. The lter type can be
set to dictate how aggressive the slope decreases the amplitude of the
frequencies below the set point.
Frequency: Set between 20Hz to 20kHz.
Filter Type: Set to 6dB, 12dB, 18dB, or 24dB
