RTI AD-46-100 - Page 13

AUDIO DISTRIBUTION
13
www.rticontrol.com
Digital Audio Inputs
TheAD-46-100andAD810-100digitalaudioinputssupporteitheraS/PDIFoptical(TOSLINK)orcoaxial
connector.Thesedigitalaudioinputsareonlyavailableforuseasinputs1and2ontheAD-46-100
andinputs1through4ontheAD-810-100.Additionally,alldigitalaudioinputsfeatureaudiooutputs
thatmirrortheinputsourcesignalsforusewithadditionaldownstreamampliersorotherexternal
equipment.
1. Connectthemaleconnectorfromoneendofanopticalorcoaxialdigitalaudiocabletooneofthe
opticalorcoaxialdigitalaudioinputports(1-2ontheAD-46-100or1-4ontheAD-810-100)onthe
amplier.
2. Connectthemaleconnectorsontheoppositeendoftheopticalorcoaxialdigitalaudiocabletoan
appropriatedigitalline-levelaudiosource.
3. Optionally,connectthemaleconnectorfromoneendofanopticalorcoaxialdigitalaudiocableto
oneoftheopticalorcoaxialdigitalaudiooutputports(1-2ontheAD-46-100or1-4ontheAD-810-
100)ontheontheampliertothedigitalaudioinputsonadownstreamAD-46-100orAD-810-100
amplierusingsteps1and2above.
ETHERNET
IN OUT DIGITAL OUT
12V
MusicStreamer
