Installation
RackInstallation
BoththeAD-46-100andAD-810-100ampliersareshippedwithrack-
mountingaccessories.Theseamplierswillconsume2RUorrack-
mountingspace.Bydefault,bothampliersareshippedwithattached
footpadsforinstallationinacabinetoronashelf.Thesefeetarenot
requiredtoberemovedforrackinstallationwhenkeepinga1RUspace
belowtheunitforproperventilation.Thesefeetcanberemovedifdesired.
Pleaseusetheincludedhardwaretoattachtherack-mountearstotheamplier’s
chassis.
 Pleasenotethata1RUspaceshouldbemaintainedaboveandbelowthechassis,whenpossible,to
allowtheowofairtoprovideproperventilationfortheproduct.Failingtodosomaycausetheunit
tooperateatahighertemperatureandmayleadtoashortenedlifespanordamage/failure.
Cabinet/ShelfInstallation
Placetheampliersonashelforcabinetthathasatleast6”(15cm)ofspaceonbothsides,behind,
andabovetoallowproperventilationandallowairtocirculateanddissipateheat.Ifplacingina
cabinet,pleaseensurethatthereisadequateventilation,eitherpassiveoractive,sothattheambient
temperatureintheallottedspacedoesnotexceed104°F(40°C).
POWER STATUS
Model AD-810-100
Audio Distribution 8x10 DSP Matrix Amplifier - 100W
6”/15cm 6”/15cm
6”/15cm
