Dashboard
Option Description
Zones
Displaysallzonesalongwiththeirassignablenamesandnumericvolumelevels
(0-100).Thevolumecanbeadjustedusingtheslidingbar.
SystemInfo
TheSystemInfosectiondisplaysthefollowing:
• Temperature:Thecolor-codedradialgaugedisplaysthecurrentinternal
temperatureandindicatesviacolorwhethertheamplierisoperatingwithin
acceptable(green)orunacceptable(red)limits.
ClickontheCorFtochangetheunittoeitherCelsiusorFahrenheit.
• Name:Displaysthenamegiventotheamplier(modiableelsewhereintheGUI).
• Model:Thisisthemodeloftheamplier.
• FirmwareVersion:Displaysthecurrentrmwareversion.
• IPAddress:Displaystheamplier’sIPaddress.
• MACAddress:Displaystheamplier’sMACaddress.
• SerialNumber:Displaystheamplier’sserialnumber.
AmplierStatus
Thissectionisdesignedtovisuallyshowtheuserwhenaparticularzone(s)isin
operation.
• Zonesinoperationwilldisplayagreenindicator.
• Zonesthatarenotinoperationwilldisplayagrayindicator.
