Connections
TheAD-46-100andAD-810-100arebothequippedwithconnectivitythatsupportsbothanalogand
digitalaudiosources.Additionally,speakersareconnectedviaincludedphoenixcaptivescrewterminals.
Peripheraldataportsforvariousmeansofcontrolarealsopresent,suchasRS-232andRJ-45.Pleasesee
belowforproperconnectioninstructions.
 Pleasenotethatallconnections,sources,speakers,ordatacables,shouldbemadewhenthe
amplierisnotpoweredasdoingsomaycausedamage/harmtoeithertheamplier,speakers,or
theinstaller.Pleaseensurethatpowerisnotonorpowerisnotconnectedtotheamplierbefore
proceedingtoaddorremoveanyconnectionstotheamplier.
Power
PowerissuppliedtotheAD-46-100orAD-810-100(TypeC14male)directly
viaanACpowermainsoutletusingtheincludedIECpowercable.An
appropriateregion-specicIECpowercable(TypeC13femaletoUS/UK/
EU/AU)isincludedwitheachamplier.Thisproductiscapableofoperating
between100-240Vinboth50/60Hzregions.
1. ConnecttheincludedIECpowercable(TypeC13female)totheamplier’s
powerinput(TypeC14male).
2. Connecttheregion-specicpowerplugtoamain’sACpoweroutlet.
PleaseensurethatthisamplierisconnectedtoanACoutletthatcan
supplytheratedpowerdrawforeachamplier(AD-46-100:800W&AD-
810-100:1200W).Connectingthisproducttoacircuitthatisinadequate
willresultinabreaker-tripandmaycausedamagetothisorother
devices/equipmentconnectedtothesamecircuit.
ControlInterfaces
TheAD-46-100andAD-810-100areequippedwithvariouscontrolinterfacesthatallowexternalcontrol
oftheampliers.TheconnectionsincludeIR,RS-232,and12Vtriggerports.Cablesfortheseconnections
arenotsuppliedandwillneedtobesourcedbytheinstaller.
Ethernet Control
TheAD-46-100andAD-810-100canbecontrolledviaTCP/IPusingbuilt-inAPIcommands.Pleaseseethe
APIappendixforalistofcommandsthatareapplicabletotheseproducts.
Power
Cable
