RTI AD-46-100 - Page 7

AUDIO DISTRIBUTION
7
www.rticontrol.com
No. Name Description
7 TCP/IPand
RS-232Control
Interfaces
EthernetconnectstoaTCP/IPlocalareanetworkforWEBGUIaccessand3rd
partycontrol.Forserialcontrol,connectthisportdirectlytoanRTIprocessor
viaastandardCAT-5eorbetterpatchcable.
8 5-12VOutput
Triggers
Thisampliercancontrolupto2additionaldevicesusingtheseoutputtrig-
gers.Thisconnectionacceptsa3.5mmmono(TR)plugthatisthenconnected
todownstreamdevicestomanagetheirpowerstates.
9 IRInandOut ControlthisamplierusingIRcommandsusingeitheradirectconnectiontoa
3rdpartycontrolsystemoranexternalIRreceiver(soldseparately)connected
totheIRInport.ReceivedIRinputsignalsareconcurrentlyrelayedoutoftheIR
Outporttoallowdaisy-chainingmultipleampliers.
PleasenotethattheIRcommandsetisasubsetofallavailablecommands.
10 Bridgeable
LoZSpeaker
Terminals
Connectstoasingle(bridged)orpairofLoZ4/8/16Ohmspeakers.Bridgingis
managedintheZonesettingssectionoftheamplier’sGUIorcontrolAPI.
11 Product
InformationQR
Code
ScanthisQRcodewithamobiledeviceforquickandeasyaccesstoinstallation
andotherproductresources(internetrequired).
12 IECPower
Connectorand
Fuse
ConnecttoanappropriatelyratedpowersourceusingtheincludedIECpower
cable.ThereplaceablefuseislocatedbelowtheIECconnectorbehindacover
thatmustberemovedforreplacement.
