AUDIO DISTRIBUTION
Technical Support: support@rticontrol.com - Customer Service: custserv@rticontrol.com 6
No. Name Description
4 AnalogAudio
Inputsand
Outputs
LeftandRightRCAmonochannelpairswithloop-outsforexternalaudiouse/
extensionofeachsource
5 DigitalAudio
Inputsand
Outputs
CoaxialandOpticalS/PDIFdigitalaudioinputsthatsupportamaximumof2
channelLPCMaudio.Eachamplierhasalimitednumberofavailabledigital
inputsthatcanbeselectedasanalternatesourcetotheirnumberedanalog
counterparts(Inputs1-2fortheAD-46-100&inputs1-4fortheAD-810-100).
Digitalinputs1and2oneachamplieralsoincludesloop-outsforexternal
audiouse/extension.
6 Congurable
Mono/Stereo
Pre-Outputs
2LeftandRightRCAmonochannelpairsthatcanbetsettooperateasstereo
ormonovariableleveloutputstobeconnectedtoanexternalamplieror
processor.
AD-46-100RearPanel
AD-810-100RearPanel
❹ ❺ ❻ ❼❽❾
󱢳 󱢴 󱢵
❹ ❺ ❻ ❼❽❾
󱢳 󱢴 󱢵
