CONNECTING THE AC ADAPTER
The included 120 Volt AC adapter must be connected to the POWER jack on
the XP-8. When the AC Adapter is connected to a power source, the display
will light and show the power-up sequence.
CHAPTER 3 | INSTALLATION
RACK MOUNT
The XP-8 can be mounted in a component rack as part of a comprehensive
control system. Remove feet before mounting in a rack.
FREE STANDING
The XP-8 ships with four removable feet that allow the XP-8 to be placed
on a at surface.
Foot
Foot
XP-8 USB PROGRAMMING PORT
USB Programming Port, for downloading software
