CHAPTER 6 | SPECIFICATIONS
Power Supply +12VDC, 1.25A
Multi-Purpose
Output Ports
Eight custom 3.5mm 4-conductor jacks, designed
for RTI modules (Sense input/RS-232 output) as
well as industry standard IR emitters.
IR Output Drive 100mA maximum (per port, adjustable)
200mA maximum (high IR output port)
IR Frequency
Transmission Range
15kHz - 460kHz
Infrared Input Compatible with industry standard repeaters
and receivers.
Relays Eight, 3 Amps @ 30 VDC or 12V/100mA Trigger
Sense Inputs Eight, Analog/Digital/Closure, 2 - 12 VDC
RS-232 Ports Eight, RJ-45 Connections, bi-directional,
110 bps - 115 Kbps, (adapters included)
Ethernet 10/100 Base-T
USB Ports Two Host, 1 Programming
RTI COMM RJ-45, bi-directional RF communication
Expansion Port RS-485 / IR / PWR
Memory Expansion SD/MM Card Slot
Display High-contrast STN LCD, 32h x 122w pixels
Display Size
(H x W)
0.7 in x 2.8 in (18mm x 60mm)
Backlights Blue LED (Display/Keypad)
Mounting Rack-mount or free standing
Dimensions
(W x H x D)
17 in (432mm) x 1.75 in (43mm) x 6.4 in
(162mm)
Weight 4 lb. (1814g)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
