RTI Under Control XP-8 User Manual

15
It’s Under Control
®
The XP-8 can connected in many different ways to control a virtually
unlimited number of devices. The following diagram illustrates just some
of the options.
CHAPTER 4 | CONNECTION OPTIONS
REAR I/O PORTS
Each IR output can drive up to four emitters directly.
More than four emitters require an amplied connecting block.
Video
Direct to Back Panel IR Port.
Use IR emitter adapter cables.
Single or Dual Emitters.
Use IR emitter adapter cables.
IR Emitter
Video equipment with
Composite output
CM-232 Communication Module
Optional accessories shown are sold separately.
Voltage
IR Emitter
Source equipment with
switched outlet.
Power supply
To Source Equipment,
Surround Processors,
Lighting Systems, etc.
Connecting Block
