CHAPTER 5 | OPERATION
MAIN MENU (continued)
STATUS (continued)
SYSTEM STATUS
TIME/DATE
Displays the current time settings.
• Current Time and Date
• Time Zone
• Sunrise Time and Sunset Time
STORAGE
Displays the memory and storage status of the XP-8
Ext Storage
• Displays external storage status
Memory (RAM)
• Displays internal memory (RAM) status
Int Storage
• Internal Storage - Displays internal storage status
CONFIGURATION STATUS
LAT/LONG
• Displays current latitude and longitude
PROGRAM INFO
Displays the XP-8 and system zone code information
dened in Integration Designer™
• System Name = Name of XP-8 (dened in Integration
Designer™)
• Macro Engines = Number of macros that can run
simultaneously
• System Zone Code = Zone code used for system le
• Device Code = Code assigned to device in system le
NETWORK
Displays current network settings.
• IP = IP Address
• Sub = Subnet Mask
• Gateway = Gateway IP address (may be missing if no
gateway is dened)
• DNS = DNS IP address
• DHCP or Static = Displays which method of IP address
conguration being used
• MAC = MAC Address
