RTI XP-3 - Diagram

Remote Control Processor
XP-3
12
CHAPTER 2 | FEATURES
IR Output Adjustment Controls
Ethernet
RS-232
USB
Power
Supply
Output Ports:
- Port 1 = MPIO
- Ports 2 & 3 = IR only
+12VDC
Sense inputs (2)
NOTE: Sense input #1 can also be congured as an input
for RTI RM-433 antennas or RTI in-wall controllers.
Relays (2)
Status Lights
Reset Button
Antenna
