RTI XP-3 User Manual

21
It’s Under Control
®
CHAPTER 4 | SPECIFICATIONS
Power Supply +12VDC, 1A
Multi-Purpose Output
Port
One, custom 3.5mm 4-conductor jack, designed
for RTI modules (Sense input/RS-232 output) as
well as industry standard IR emitters.
Infrared Output
Ports
Two, 3.5mm jacks, compatible with industry
standard IR emitters
Infrared Output
Drive
100mA maximum (per port, adjustable)
Infrared Frequency
Transmission Range
15kHz - 460kHz
Sense Inputs Two, +3-24VDC
RS-232 Ports One, Bi-directional RJ45 Connection
Ethernet Port One, 10/100Base-T with Power-over-Ethernet
(Class 3)
USB Ports One, Type B, Programming and rmware updates
Relays Two, 5 Amps @ 30 VDC Max
Mounting Wall-mount or free standing
Dimensions
(W x H x D)
7.0” (177mm) x 3.0” (76mm) x 1.0” (25mm)
Weight 6.4 oz. (100g)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
