Remote Control Processor
XP-3
20
Optional accessories shown
are sold separately.
RJ-45>DB-9 Adapter
Lighting, security, media
server or other supported two-
way enabled devices
CHAPTER 3 | INSTALLATION AND OPERATION
CONNECTION OPTIONS (CONTINUED)
XP-3 connection examples:
Receiver or source equipment
with switched outlet.
Drapes
Relays
Voltage Sense Inputs
Voltage source wired to
Sense In 1 or 2 and Ground
RS-232 Control (cat5)
Voltage Source:
Such as a power supply
plugged into switched outlet.
