ZoneFlex P300 Wireless Bridge User Guide, 800-70956-001 Rev B 82

5GHz 24dBi Point-to-Point 2x2 Dual-

Polarized Directional Outdoor Antenna

911-2401-

DP01

7- to

9-degree

beamwidth

Table 13. Ruckus Wireless customer-orderable 5GHz antennas (Continued)

Part Ruckus

Wireless

P/N

Notes
