J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
22 V1.032818
4.3.1 Equipment/Material Required
Grout Mix: Non Shrink Type.
Sufficient lumber for foundation template and grout trough.
Risers or funnels for guiding grout.
Sufficient oil paint for grout protective covering.
Dial indicator.
One bracket, suitably stiff having an arm length of sufficient length to extend from the driver
coupling hub to the pump coupling hub.
4.3.2 Grouting Precautions
During all the grouting process, the involved personnel must follow these safety precautions:
1. Wear goggles or face shields, aprons, and protective gloves at all times.
2. Wear dust masks if in contact with the dry aggregates.
3. Wash hands regularly with soap and water.
Some epoxy grouts have highly exothermic reactive properties; they should be
handled with care. They may become extremely hot and cause severe burns.
4.3.3 Grouting Procedure
1. Verify that anchored bolt sleeves are clean and dry. Fill them with a nonbonding moldable
material to prevent them from being grouted.
2. The anchor bolt threads should be protected with tape before grouting.
3. Provide a form around the baseplate to contain the grout. The form should be chamfered at
all corners.
Grout forms should be attached with drilled anchors. Do not power nail.
Apply three coats of paste wax to the inside surfaces of the forms in order to
prevent adherence. Do not use oil or liquid wax.
