J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
6 V1.032818
1. PRODUCT DESCRIPTION
These operating instructions contain important information about the installation, operation and service
of the unit. It is therefore imperative that the installing engineer and the responsible
specialist/operating personnel read and understand these operating instructions before installation and
commencement of operation.
This manual must always be available in the operational area of the machine/plant.
IMPORTANT: For any component/accessory that has not been manufactured by Ruhrpumpen and is part
of the pump’s equipment, a complete reading of said component/accessory manufacturer’s manual
must be carried out for further information on proper maintenance procedures and relevant safety
warnings.
Correct and orderly installation/assembly is necessary for trouble-free operation of the unit.
Ruhrpumpen does not assume any liability for damage resulting from inadequate installation/assembly.
The chosen location for installation must offer enough space for maintenance activities. Ruhrpumpen
recommends consulting also API Recommended Practice 686 to ensure proper installation in your
facility.
Please contact a Ruhrpumpen representative should problems arise. The pump may only be opened by a
Ruhrpumpen approved technician during the guarantee period.
In case of queries, please have your project number and type designation of the pump available. You can
find both of these on the first page of these operating instructions or on the rating plate fixed to the
pump.
When ordering spare parts we would further request that you give the description of the required parts,
together with their part numbers and identity numbers. You can find these on the sectional drawing and
spare part list enclosed.
1.1 INTRODUCTION
Ruhrpumpen pumps of type J Line are horizontal, single stage, double suction, double volute radially
split case centrifugal pumps. J Line pumps offer various configuration options, with upper suction and
discharge flanges for the J and JD configurations and side suction and discharge flanges for the JS and
JDS configurations. The main difference between the J and JD configurations is that the J configuration is
equipped with a single axial case cover while the JD configuration offers both axial and radial casing
covers. All J line pumps are designed to comply with the latest edition of API 610. These pumps are
designed for continuous duty pumping of various fluids with combinations of metallurgical, mechanical,
and installation features for application in petroleum, petrochemical, water and industrial products
