Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
36
Operating Height
0 to 5000 m (3.11 miles) above the sea level
5% to 90% RH
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMI Certification
GB9254-2008CLASS A
Safety Regulation
Compliance
GB4943-2011
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4.6 kg (10.14 lbs.)
Appearance
The front panel of the RG-S5310-48GT4XS-P-E switch provides 48 10/100/1000Base-T Ethernet ports (PoE+ capable), four 10GE SFP+
ports, one management port, one Console port and one USB port. The back panel has two power supply module slots.
Figure 1-37RG-S5310-48GT4XS-P-E Switch Appearance
Front Panel
Figure 1-38 Front Panel of RG-S5310-48GT4XS-P-E
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. LED Mode Indicator
6. LED Mode Button
7. USB Port
8. Console Port
9. Management Port
10. 10/100/1000Base-T Ethernet Port
11. 10GE SFP+ Port
12. Port LED
