Ruijie Reyee RG-ES1 Series User Manual

Hardware Installation and Reference Guide Product Overview
8
Ports 1 to 8 support PoE/PoE+ with the maximum power output of 30 W per port. Ports 9–10
do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 110 W.
Power
Consumption
Less than 8 W with no PoE load
Less than 129 W with PoE full load
Operating
Temperature
0°C to 45°C (32°F to 113°F)
Storage
Temperature
-40°C to +70°C (-40°F to +158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Port Mode
Switchover in three modes:
1. Flow Control On
2. Flow Control Off
3. Port Isolation
When port isolation is enabled, ports 1-8 are isolated from each other, but can communicate
with ports 9 and 10.
Fan
Not supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
Certification
CE
Earth Leakage
Current
≤ 1.5 mA
Dimensions
(W x D x H)
190 mm x 100 mm x 28 mm (7.48 in. x 3.94 in. x 1.1 in.)
Weight
(With Package)
1.3 kg (2.87 lbs)
Device operation in a residential environment may cause radio interference.
Product Appearance
The RG-ES110D-P provides eight 10/100Base-TX auto-sensing Ethernet ports, two 10/100/1000Base-T auto-sensing
Ethernet ports, and LED indicators on the front panel, and a power socket, a port mode switchover button, and a grounding
pole on the back panel.
Figure 1-7 Appearance of the RG-ES110D-P
