Ruijie Reyee RG-ES1 Series

Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
The RG-ES100 series switches include the following models.
Model
10/100Base-TX Auto-sensing
Ethernet Port
10/100/1000Base-T
Auto-sensing
Ethernet Port
1000Base-X SFP
Port
Console
Port
RG-ES106D-P
6 (ports 1–4 support PoE/PoE+)
N/A
N/A
N/A
RG-ES126S-LP
24 (ports 1–24 support PoE/PoE+)
2
1 (combo)
N/A
RG-ES110D-P
8 (ports 1–8 support PoE/PoE+)
2
N/A
N/A
RG-ES116G
N/A
16
N/A
N/A
RG-ES124GD
N/A
24
N/A
N/A
RG-ES118S-LP
16 (ports 1–16 support PoE/PoE+)
2
2 (combo)
N/A
1000Base-T is backward compatible with 100Base-TX and 10Base-T.
The SFP ports cannot be backward compatible with 100Base-FX.
1.1 RG-ES106D-P
Technical Specifications
Model
RG-ES106D-P
Ports
Six 10/100Base-TX auto-sensing Ethernet ports
Ports 1–4 support PoE/PoE+.
Power Supply
 AC input
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50/60 Hz
Rated current: 1.5 A
 Adapter output
Rated voltage range: 51 V DC
Rated current range: 1.25 A
EEE
Not supported
PoE
PoE/PoE+ support
Ports 1 to 4 support PoE/PoE+ with the maximum power output of 30 W per port. Ports 5–6 do
not support PoE or PoE+.
The overall maximum output power of PoE or PoE+ is 58 W.
Power
Consumption
Less than 7 W with no PoE load
Less than 67 W with PoE full load
Operating
Temperature
0°C to 45°C (32°F to 113°F)
